Specifications

Analytical Method	Energy-dispersive X-ray Fluorescence
Element Measuring Range	Atomic Number From 11 To 92 [Sodium (Na) To Uranium (U)]
Analytical Range	ppm to 99.99%
Analysis Time	30 to 200 s
Analysis Accuracy	RSD ≤ 0.1 %
Energy Resolution	100 eV
X-Ray Tube Current	5 µA to 1000 µA
X-Ray Tube Voltage	5 KV to 50 KV
Vacuum Rate	10-2 pa in 10 s
Vacuum Pump Power Consumption	550 W
Detector Type	Electric refrigeration FAST-SDD semiconductor
Detector Photon Counting Rate	500000 CPS
Detector Signal to Noise Ratio	6500 is to 1
Analyzer Type	2048 channelled digital multichannel analyzer
Modes Of Operation	2, Linear and pulse
Pulse Mode Type	Triangular pulse shaping
Pulse Forming Time	2 μs
Spin System Speed	4 r/s
Spin System Current	1.5 A
Spin System Voltage	24 V
Camera System	500 million pixels High-definition camera
Ambient Humidity	30% - 80%
Sample Chamber Size	170 × 39 mm
Power Consumption	100 W
Power Supply	AC 220V ±10%, 50Hz
Dimension (W × D × H)	700 × 650 × 800 mm
Weight	80 kg

Features

• Non-destructive analysis
• Both pulse and linear mode of operation
• Highly accurate elemental detection
• Built-in signal-to-noise enhancer
• Automatic collimators and filters

Applications

• X-ray Fluorescence Spectrometer performs non-destructive analysis of samples in research, mining, geology, forensic, agriculture, pharmaceuticals, electronics, food and construction industries.

Accessories

• Instrument Host	1 piece
  Computer	1 piece
  Laser Printer	1 piece
  Analysis Software	1 set
  Vacuum System	1 set
  Portable Vacuum Cleaner	1 piece
  Manual Tablet Press	1 piece
  Regulated Power Supply	1 piece
  Reference Materials	1 set
  S Standards	1 set

Accessories Optional

• Vibration Mill: 50 g, 100 g

  ---

  Automatic Tablet Press
