| Analytical Method | Energy-dispersive X-ray Fluorescence |
| Element Measuring Range |
Atomic Number From 11 To 92 [Sodium (Na) To Uranium (U)] |
| Analytical Range | ppm to 99.99% |
| Analysis Time | 30 to 200 s |
| Analysis Accuracy | RSD ≤ 0.1 % |
| Energy Resolution | 100 eV |
| X-Ray Tube Current | 5 µA to 1000 µA |
| X-Ray Tube Voltage | 5 KV to 50 KV |
| Vacuum Rate | 10-2 pa in 10 s |
| Vacuum Pump Power Consumption | 550 W |
| Detector Type | Electric refrigeration FAST-SDD semiconductor |
| Detector Photon Counting Rate | 500000 CPS |
| Detector Signal to Noise Ratio | 6500 is to 1 |
| Analyzer Type | 2048 channelled digital multichannel analyzer |
| Modes Of Operation | 2, Linear and pulse |
| Pulse Mode Type | Triangular pulse shaping |
| Pulse Forming Time | 2 μs |
| Spin System Speed | 4 r/s |
| Spin System Current | 1.5 A |
| Spin System Voltage | 24 V |
| Camera System | 500 million pixels High-definition camera |
| Ambient Humidity | 30% - 80% |
| Sample Chamber Size | 170 × 39 mm |
| Power Consumption | 100 W |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimension (W × D × H) | 700 × 650 × 800 mm |
| Weight | 80 kg |
