| Type of specimen | Solid or Suspension liquid sample |
| Range of measurement | 0.1 to 30.0 mg |
| Control Mode | PC software controlled |
| Analysis Parameter | TC, TIC, TOC (TC-IC) |
| TC Measurement Method | High-temperature catalytic combustion |
| Temperature Range | 900℃, Maximum 1000℃ |
| Measurement Time | 5 to 8 min |
| Sample holder | Quartz boat |
| Gas Requirement | Oxygen, purity ≥ 99.995% ( TOC analyzer provides) |
| Flow rate | 500 mL/min |
| Maximum Sample |
Solid: 1.0g TC liquid: 0.5 mL IC liquid: 0.3 mL |
| Power Supply | AC100 to 240V, 50/60 Hz |
| Power Consumption | 1000 W |
| Packing Dimension | 863 × 648 × 522 mm |
| Gross Weight | 50 Kg |
