Specifications

Temperature Range	20℃ to 300℃
Temperature Resolution	0.01℃
Sample Size	50 mm
Sample Thickness	0.1 to 30 mm
Accuracy	≤± 3%
Repeatability	± 2%
Thermal Conductivity Range	0.010 to 45W/mK
Thermal Resistance	0.000005 to 0.05 W(m²K)
Refrigeration System	Compressed air /external water bath
Force Control Range	0 to 1000N
Displacement Control	0 to 30 mm
Room Temperature	18℃ to 28℃
Humidity	20 to 80% RH
Data Result Analysis	Automatic thermal analysis software
Certifications	D5470-06, ASTM E1530, ASTM C 518, ISO 8301, JIS A 1412, DIN EN 12939, DIN EN 13163, and DIN EN 12667
Power Consumption	3.0 kW
Power Supply	220V/ 50 Hz
Host Machine Dimensions	65 × 58 × 107 cm
Water Tank Dimensions	48 × 42× 88 cm
Weight	130kgs

Features

• Features auto plate movement to minimize manual adjustments
• Allows precise programming of temperature conditions for tests
• Designed for testing materials with low to medium thermal conductivity
• Customizable test configurations allow users to save settings for different materials
• Enhanced with efficient calibration management
• Provides a user-friendly interface for real-time monitoring of test data
• Stores all data for efficient record-keeping and analysis

Applications

• Commonly used in material development, the construction industry, electronics and semiconductors, the automotive industry, and the aerospace industry, it is applied to evaluate the heat transfer rate, offering an accurate measurement of a material's thermal conductivity.

Accessories

• YY-II-RL Testing Host

  ---

  Thermostatic Water Bath

  ---

  Testing Software (USB)

  ---

  Reference Sample
