Specifications

Wavelength Range	195 to 800 mm
Elements Per Minute	10 elements
Standard Deviation	RSD <1.5%
Stability	RSD <3%
Relative Coefficient	>0.9995%
Element Limit of Detection	Element Wavelength(nm) LOD(ppb&ug /L) Ag 328.06799999999998 0.3 A1 396.15199999999999 2 As 193.696 4 Au 242.79499999999999 1 B 249.773 1 Ba 445.40300000000002 0.1 Be 313.04199999999997 0.2 Bi 223.06100000000001 5 Ca 396.84699999999998 0.2 Cd 214.43799999999999 0.3 Ce 413.76499999999999 1.5 Co 228.61600000000001 1 Cr 267.71600000000001 1 Dy 324.75400000000002 1 Er 353.17 0.3 Eu 337.27100000000002 0.3 Fe 381.96699999999998 0.3 Ga 238.20400000000001 1 Gd 294.36399999999998 3 Hf 342.24700000000001 0.5 La 277.33600000000001 1 Lu 345.6 0.5 Mg 333.74900000000002 0.5 Mn 261.54199999999997 0.2 Mo 279.553 0.2 Ag 202.03 1 Al 328.06799999999998 0.3 Nb 396.15199999999999 2 Nd 401.22500000000002 1.5 Ni 221.64699999999999 1 P 213.61799999999999 6 Pb 220.35300000000001 5 Pd 340.45800000000003 2 Pr 390.84399999999999 2 Re 227.52500000000001 3 Sb 206.833 0.5 Sc 196.02600000000001 8 Se 251.61099999999999 5 Si 359.26 1 Sm 235.48400000000001 10 Sn 407.77100000000002 0.15 Sr 226.23 6 Ta 350.91699999999997 1 Tb 334.94099999999997 0.2 Ti 261.86099999999999 5 T1 313.12599999999998 0.3 Tm 309.41800000000001 0.5 V 207.911 4 W 371.03 0.2 Y 328.93700000000001 0.2 Yb 213.85599999999999 0.5 Zn 343.82299999999998 0.4 Zr 343.82310000000001 1 Nb 401.22500000000002 1.5 Nd 396.15199999999999 2
Dimension	168 ×74 ×132 mm
Weight	190 Kg

Features

• Included a super steady signal, a very bright light, and the ability to see things even if they're super tiny, like one part in a billion
• Measure things over a huge range, from very tiny to very large
• Extremely fast measurement speed
• Exceptionally low detection limits
• Quick analysis at a rate of 10 elements per minute
• Figure out 600 samples per day
• Extensive measurement range, from ultra-volume to continuous analysis
• Examine a broad range of elements, including 70 metallic and several non-metallic elements.

Applications

• ICP Spectrometer is utilized for analyzing samples in various fields such as machinery, steel, rare earth, magnetic materials, health, biology, nuclear industry, agriculture, food inspection, water quality, and more.
