- ✔ 5 inch LCD display
- ✔ Wavelength range 190 nm to 1100 nm
- ✔ Spectral bandwidth 0.5,1, 2 and 4 nm
- ✔ 1200 lines / mm grating optical system
- ✔ Wavelength repeatability 0.2 nm
- ✔ Built in UV-Vis Analyst software eliminates need of additional software
- ✔ Solvent resistance tactile keypad with alphanumeric entry for file names and units
- ✔ Pre-aligned deuterium lamp for easy replacement
- ✔ Real time clock for date and time stamping of results
| Wavelength range |
190 nm to 1100 nm |
| Spectral bandwidth |
0.5, 1, 2 and 4 nm |
| Optical system |
Single beam, grating 1200 lines / mm |
| Wavelength accuracy |
± 0.3 nm |
| Wavelength repeatability |
0.2 nm |
| Scanning mode |
High, Medium and Low (Adjustable) |
| Maximum scanning speed |
3000 nm / min |
| Photometric range |
T: 0 to 200% , A: (-0.3) to 3, C: 0 to 9999 |
| Photometric accuracy |
T: ≤ ±0.5%, A: ±0.005 % @ 1 A |
| Light source |
Halogen and deuterium lamp (pre-aligned) |
| Stray light |
≤ 0.05 % T @ 220, 340 nm |
| Stability |
±0.002 A/h @ 500 nm |
| Display |
5 inches LCD (320 × 240 dots) |
| Baselines flatness |
± 0.002 A (200 to 1000 nm) |
| Standard cell holder |
4 position 10 mm cell changer |
| Sample compartment |
Standard 10 mm path length cuvette |
| Detector |
Silicone photodiode |
| Output |
USB port and parallel port (printer) |
| Power requirement |
AC 110 / 220 V, 50 / 60 Hz |
| Dimensions (W × D × H) |
600 ×450 × 200 mm |
| Weight |
20 kg |
Used for clinical, pharmaceutical, bio-chemical lab, and also for routine applications such as quantitative analysis, kinetics, wavelength scanning, multi-wavelength and DNA/Protein analysis.
