    Real Time PCR FM-RTP-A101

    Real Time PCR FM-RTP-A101

    Real Time PCR FM-RTP-A101 offers precise and efficient quantitative analysis of nucleic acids. This advanced device can accommodate up to 96 samples and features six fluorescent detection channels. Its creative design minimizes multi-color crosstalk and eliminates edge effects. Advanced Optical scanning detection system enhances signal accuracy and reproducibility. With its robust design and innovative features, the PCR ensures reliable performance, high sensitivity, and user-friendly operation.

    Catalog Buy Now
    • ✔  Real time PCR with improved sensitivity
    • ✔  Reliable results without the need for ROX correction
    • ✔  Time-resolved signal separation technology
    • ✔  Precise data analysis with no background noise
    • ✔  Edge temperature compensation technology
    • ✔  Consistent and accurate amplification

    Sample capacity 96 wells
    Reaction volume 10 to 50 μL
    Thermal cycle technology Peltier
    Maximum Heating/Cooling rate 6.0° C/s
    Heating temperature range 4 to 100 °C
    Temperature accuracy ± 0.2 °C
    Temperature uniformity ± 0.2 ℃ at 60 ℃, ± 0.3 ℃ at 95 ℃
    Temperature gradient setting range 30 to 100 °C
    Temperature gradient difference setting range 1 to 36 °C
    Excitation light source 4 monochrome high efficiency LEDs
    Detector PMT
    Detection mode Time-resolved signal separating technology
    Excitation/detection wavelength range 455 to 650 nm/510 to 715 nm
    Fluorescent channels 5 channels
    Supported dye FAM/SYBR Green, VIC/JOE/HEX/TET, ABY/NED/TAMRA/Cy3, JUN, ROX/Texas Red, Mustang Purple, Cy5/LIZ
    Sensitivity Single copy gene
    Resolution 1.33 folds copy number difference can be distinguished in single-plex qPCR
    Dynamic range 10 orders of magnitude copies
    Packing Dimension (W × D × H) 960 × 660 × 750 mm
    Gross weight 47 Kg

    Real Time PCR has wide applications across scientific research, clinical diagnostics, quality control, safety testing, and forensic sciences.
