- ✔ Compact and efficient device with quiet operation and secure closures
- ✔ Includes special driver gear that reduces noise by 15-20 dB compared to common gear
- ✔ Equipped frequency converter controls that allow setting up speed according to experiment needs
- ✔ Ideal for simple mixing and homogenization and facilitates the use of 2 or 4 jars every time according to your need
- ✔ Uses the variable frequency drive to fine-tune the motor's speed
- ✔ Structured with stainless steel zirconia jar that ensures safety and long-term usability
- ✔ Convenient Cleaning with safety and sanitation
| Max Volume of Pot or Jar |
100ml |
| Work Mode |
2 or 4 jars working together |
| Mill Mode |
Dry/wet milling |
| Speed Frequency |
Adjusting |
| Drive Mode |
Gear drive |
| Rotational Speed |
90-870 r/min, adjusting |
| Revolution: Rotation |
1:2 |
| Material Capacity |
Material + mill balls < 2/3 volume |
| Input Granularity Size |
≤ 10mm for soft material
≤ 3mm for hard material |
| Output Granularity Size |
Minimum 0.1μm |
| Feed Material |
Soft, hard, brittle, fibrous, cellulose, herb, glass, soil, ore, pharmacy, chemical, fluorescent, pigment, etc. |
| Grinding Jars |
Stainless steel, zirconia, alumina, nylon, PU, tungsten, PTFE, etc., vacuum jars are available as well. |
| Grinding Medium |
Stainless steel balls, zirconia balls, alumina balls, PU balls, steel carbon balls, tungsten balls, etc |
| Time Range |
72 hours |
| Voltage |
110V or 220V, 50/60 Hz Single phase |
| Dimensions |
500×300×340 mm |
| Weight |
29 kg |
It is mainly used for mixing and grinding in fields such as Geology, Mining, Metallurgy, Electronics, Construction Material, Ceramics, Chemical Engineering etc
