- ✔ Microprocessor PID control system with LCD display
- ✔ 8 segment adjustable program settings of different speed and time
- ✔ Powder coated steel construction
- ✔ Single shaft drive technology
- ✔ Chrome alloy and iron casting key parts
- ✔ Recovery function after power cut-off
- ✔ Over speed acoustic and visual alarm function
- ✔ Slow start circuit prevent sudden start and liquid splash
- ✔ Power cut off protection for overheating motor and over temperature
- ✔ Frequency control system with accuracy ± 1 rpm
- ✔ Large torque converter motor
| Controller |
PID (Environmental Scanning Microprocessor） |
| Shaking mode |
Orbital |
| Shaking speed |
30 to 250 rpm |
| Shaking accuracy |
± 1 rpm |
| Vibration range |
100 mm |
| Shaking plate size |
840 × 620 mm |
| Program control |
8 segments (adjustable) |
| Working environment temperature |
Constant room temperature (indoors) |
| Drive mode |
Single shaft balance device |
| Convection mode |
Natural convection |
| Display |
LCD (simultaneous display of working and set parameters) |
| Timing range |
0 to 999.59 h continuous |
| Shaking plate quantity |
1 pc |
| Chamber material |
Polished stainless steel |
| External material |
Steel with powder coating |
| Safety function |
Audio and visual alarm for over temperature, alarm for over speed |
| Power |
150 W |
| Power supply |
AC 200 V to 240 V, 50/60 Hz |
| Dimension (W × D × H) |
900 × 650 × 480 mm |
| Net weight |
250 kg |
Used for cell culturing, staining/de-staining and general mixing in microbiology, chemistry, immunology, biochemistry, molecular biology, biopharmaceutical and biomedical laboratories.
| Flask specification |
Standard quantity |
Maximum capacity |
| Flask clamp (PCS) |
250 ml |
54 |
54 |
| 500 ml |
- |
35 |
| 1000 ml |
- |
24 |
| 5000 ml |
- |
4 |
| Note: Other sizes listed above can be offered as standard configuration to replace the size with standard quantity alternatively. |
