- ✔ Uniform sample digestion due to vertical design
- ✔ Real-time monitoring of temperature and pressure
- ✔ Contactless sensors reduce maintenance costs
- ✔ Imported vessel material enhances safety
- ✔ User-friendly color touch screen interface
- ✔ Carbon Fiber Reinforced Polymer improves durability
- ✔ 316L Stainless steel with Teflon coating provides resistance against acid corrosion
| No. of vessels |
12 |
| Vessel Volume |
100 ml |
| Temperature Monitoring |
| Temperature monitor | Contactless IR Sensor |
| Temperature control range | 50 to 400 ℃ |
| Temperature Accuracy | ± 0 .1 ℃ |
| Display Accuracy | ± 0 .1 ℃ |
|
| Pressure Monitoring System |
| Pressure monitor | Contactless Sensor |
| Pressure Control Range | 0 to 15 MPa |
| Pressure Accuracy | ± 0.01 MPa |
| Display Accuracy | ± 0.01 MPa |
|
| Sample Vessel Material |
Imported TFM |
| Protection Vessel Material |
Peek + Glass Fiber |
| Display |
7-inch Touch Screen |
| Rotation |
360° Continuous Rotating |
| Microwave Tank |
316L Stainless Steel tank With Corrosion-Proof Coating |
| Microwave Power (Adjustable) |
0 to 1000 W (Adjustable) |
| Microwave Leakage |
< 5 mw/cm2 |
| Air Exhaust |
High power corrosion-proof air blower |
| Power Supply |
AC 220 V ± 10%, 10A, 50/60 Hz |
| Dimension (L × W × H) |
490 × 560 × 630 mm |
| Weight |
47 Kg |
Microwave Digestion System is used for preparing various samples in departments like quality control, environmental monitoring, and scientific research across various industries.
Sample rotor
Auxiliary platform
Digestion vessel
Vessel holder
Pressure calibration ring
