Microplate Reader FM-MPR-B100
Microplate Reader FM-MPR-B100 has a wavelength range of 340 to 750 nm and a resolution ratio of 0.001 Abs. It provides fast and accurate measurement of 96-well plates, making it ideal for high-throughput applications. The reader is equipped with an eight-position filter wheel, with four standard filters preinstalled, allowing for a range of wavelengths. Its built-in software enables comprehensive control and data handling, ensuring ease of operation. Our microplate reader is designed to deliver consistent performance and reliability in laboratory environments.
Specifications
| Light source | 6V 10W Quartz halogen lamp |
| Wavelength Range | 340 to 750 nm |
| Filters | Four standard filters: 405 nm, 450 nm, 492 nm, 630 nm |
| Absorbance Range | 0.000 to 4.000 Abs |
| Resolution Ratio | 0.001 Abs |
| Linearity | (0.2, 0) ± 1%; (2.0, 4.0) ± 2% |
| Wavelength Indication Error | ≤ ±3 nm |
| Wavelength Repeatability | ≤ ±1.5 nm |
| Repeatability | (0.3, 0) ≤ 0.3%, (3.0, 4.0) ≤ 1% |
| Stability | (0.3, 0) ≤ 0.3%, (3.0, 4.0) ≤ 1% |
| Accuracy | (0.2, 0) ≤ ±0.005 A, (2.0, 3.0) ≤ ±1%, (3.0, 4.0) ≤ ±1.5% |
| Sensitivity | ≥ 0.010 |
| Channel Variation | < 0.01 A (1.0 Abs standard filters) |
| Measurement Speed | Single wavelength: <10 s/96 well, Dual wavelength: <16 s/96 well (normal mode) |
| Incubator Temperature | Ambient +4°C to 50℃ |
| Dimension | 280 × 432 × 220 mm |
| Weight | 10 kg |
Features
- Enables incubation temperatures up to 50℃
- Large color screen
- Built in self-diagnostics
- User-friendly interface
- Flexible plate compatibility
Applications
- Microplate Reader FM-MPR-B100 is used in ELISA immunoassays, Protein Quantification, Cytotoxicity assays in research laboratories, educational institutions, pharmaceutical companies, etc.
