Specifications

Plate Type	96-well plate
Display	7" TFT LCD Display
Wavelength Range	400 to 750 nm
Standard Wavelength	405, 450, 492, 630 nm
Band width	8 nm
Wavelength Accuracy	± 2 nm
Wavelength Precision	± 0.03 A
Resolution	0.001 Abs
Wavelength Linearity	R ≥ 0.995
Wavelength Repeatability	< 1%
Wavelength Stability	< 0.005 Abs/10min
Reading Speed	5s single wavelength
Reading Range	0.000 to 4.000 Abs
Measurement System	8 Channel Optical System
Temp. Range	10°C to 35°C
Humidity Range	15% to 85%
Shaking	Linear (slow, medium and high mode)
Light Source	Monochromatic LED
Light Source Life	More than 100000 h
Detection Method	Absorbance
Detector	Silicon Photodiode
Detection Modes	Comprehensive Qualitative and Quantitative Data-Evaluation with Cut-Offs, Curve-Fits and Transformation Formulas
Dimension	400 × 310 × 169 mm
Power	80 W
Power Supply	AC 100 to 240 V, 50/60 Hz
Weight	6 kg

Features

• Can store up to 1200 results for 96-well plate
• 7 inch TFT LCD Display
• 8-channel optical measuring system
• Single wavelength detection
• Linear shaking function at variable speed with three modes: slow, medium and high
• Two free positions for additional filters
• On-board software can store 55 user programmable protocols
• LCD light source with lifespan over 100,000 hours

Applications

• Used in drug detection and life science research, bioassay testing and quality control pharmaceutical processes.
