| Measuring Range |
Wet: 0.01μm to 2000 μm Dry: 0.1μm to 2000μm |
| Measurement Method | Laser diffraction principle |
| Analysis | Mie and Fraunhofer Light scattering |
| Detector Configuration | Logarithmic Array, Testing Angle from 0.015 to 145° |
| Silicon Sensors |
Wet:127 pcs Dry:100 pcs |
| Light Path | Reverse Fourier Optical Path (Converging Light Path) |
| Compliance Standards |
ISO13320 to 1:2009 Compliance with 21 CFR Part 11, CE |
| Focal Distance | 500 mm |
| Sample tank capacity | 1000 mL |
| Mode of Operation | Full automatic/manual control |
| Dispersion medium | Compressed Air, pressure: 0 to 6 bar |
| Optical Setup Alignment System | Full automatic, precision is up to 0.2μm |
| Test Completion Speed |
Wet: ＜2 Min Dry : <1min Time between test results: 500 ms; Standard measurement: under 10 seconds |
| Environmental Conditions |
Temperature: 5 to 35℃ Humidity：＜85% |
| Storage conditions | -20°C to +50°C |
| Accuracy error |
Wet < 0.5% Dry < 0.5% |
| Repeatability error |
Wet <1% Dry <1% |
| Illumination Source |
High-Quality Fiber Red Laser (λ=632nm ) P＞3.0MW Auxiliary blue semiconductor laser (λ= 405 nm) P＞2.0MW |
| Test Report | Word, Excel, Photo( Bmp), Text etc. |
| Laser Protection | Safety Class 1 |
| Wet Particle Dispersion |
Ultrasonic Frequency: 40KHz Power:60W Time: ≥1S |
| Stirring Speed | 0 to 3000 RPM (Adjustable) |
| Circulation Flow Rate |
30 L/min Rated Power:70 W |
| Interface | USB |
| Power Supply | 220 V , 50 /60 Hz |
| Packing Dimension Box 1 ( L× W × H ) | 1400 × 550 × 680 mm |
| Packing Dimension Box 2 ( L× W × H ) | 380 × 380 × 550 mm |
| Packing dimension Box 3 ( L× W × H ) | 860 × 450 × 750 mm |
| Packing dimension Box 4 ( L× W × H ) | 410× 410× 550 mm |
| Net Weight | 62 + 15 Kg |
| Gross Weight | 180 Kg |
