- ✔ PLC controlled system based autoclave with LCD display
- ✔ Sterilize agent: 60% Hydrogen peroxide solution (H2O2)
- ✔ Sterilization temperature is 50°C
- ✔ Hydraulic pressure is 50 Pa and Highest anti-pressure value is 10 Pa
- ✔ High strength vacuum pump to ensure fast vacuum speed and long service life
- ✔ Top rod driven electric lift door and security interlocking devices to prevent risks of false operation
- ✔ Two-layer aluminum alloy punching plates for loading sterilized articles
- ✔ Sterilization room is made-up of aluminum or stainless steel with superior anti-corrosion and thermal conductivity
- ✔ No drainage or ventilation required, zero pollution to environment
- ✔ Alarm system to indicate high or low temperature, pressure, time, cycle mode, process stage and provide the actual interface photo
- ✔ Anti-explosion and fire resistance heating system
- ✔ Test data storage up-to more than one million sterilization data
| Cabinet type |
Vertical (Full automatic) |
| Capacity |
100 L |
| Design |
Single door rectangular autoclave |
| Category |
Class B |
| Working pressure |
50 Pa |
| Ambient temperature |
5°C - 45°C |
| Working temperature |
50°C |
| Temperature accuracy |
±5°C |
| Sterilizing agent |
60% Hydrogen peroxide solution (H2O2) |
| Filter accuracy |
≤ 0.2 µm |
| Display |
LCD touch screen |
| Chamber construction material |
5052 Aluminum |
| Chamber tray |
Two-layer aluminum alloy plate |
| Sterilization period |
45 - 50 min |
| Caster |
Yes |
| Power |
3.95 kW |
| Voltage |
AC 220 V / 110 V, 50 Hz |
| Inner tank dimension (W × D × H) |
700 x 430 x 360 mm |
| Outer tank dimension (W × D × H) |
1070 x 810 x 1780 mm |
| Packaging dimension (W × D × H) |
1220 x 920 x 1860 mm |
| Net weight |
239 kg |
| Gross weight |
290 kg |
Used in the hospitals, pharmaceutical industries, laboratories and research institutes to sterilize probes, rigid endoscope, hose endoscope, ophthalmic lens, fiber optic cables, intracranial pressure sensor, esophageal dilator, electrocautery apparatus, defibrillation electrode, laser head, metal, glass, silica gel rubber etc.
