Hotplate Magnetic Stirrer FM-HMS-A103
Hotplate Magnetic Stirrer FM-HMS-A103 is a tabletop unit that offers a revolution speed range from 100 to 2000 rpm for precise mixing. It includes an adjustable thermometer rack to enhance temperature monitoring accuracy. Its heating plate reaches a maximum temperature of up to 380℃ for accurate control in high-temperature conditions. Our magnetic stirrer provides continuous operation and consistent performance for extended periods.
Specifications
| Speed Range | 100 to 2000 rpm |
| Maximum Temperature | 380℃ |
| Maximum Volume | 2000 ml |
| Plate Size | 120×120 mm |
| Plate Load | 3 kg |
| Working Time | Continuous |
| Driving Mode | Motor |
| Motor Power | 10 W |
| Heating Power | 0.18 kW |
| Stir Bar Material | PTFE |
| Setting Mode | Scale |
| Speed Display Mode | Scale |
| Timer | No |
| Operation Function | No |
| Temperature Sensor | No |
| Power Supply | 110V or 220V, 50/60Hz |
| External Dimensions (W×L×H) | 200×120×90 mm |
| Packaging Dimensions (W×L×H) | 250×180×120 mm |
| Net Weight | 1.9 kg |
| Gross Weight | 3 kg |
Features
- Adjustable heating power and stirring speed
- Stainless steel rods and the stir bar
- Flame-protected heating plate
- Aluminum exterior with surface spraying
Applications
- Hotplate magnetic stirrer is used to facilitate efficient mixing and heating in various applications such as chemical synthesis, biochemical analysis, pharmaceutical research, educational institutes, etc.
