High Speed Refrigerated Microcentrifuge FM-HMC-A101
High Speed Refrigerated Microcentrifuge FM-HMC-A101 separates small volumes of sample at 21000 rpm. Designed to operate in broad temperature conditions of -20°C to 40°C. Compatible with variety of adaptors and rotors supporting both high and low settings. Features 5-inch LCD touch screen display for real time parameter monitoring. Our Refrigerated Microcentrifuge has user-defined programs for easy centrifugation of biomolecules.
Specifications
| Maximum Speed | 21000 rpm |
| Speed Accuracy | ± 20 rpm |
| Maximum RCF | 31061 × g |
| Maximum Volume | 4 × 750 mL |
| Temperature Range | -20°C to 40°C |
| Temperature Accuracy | ±1 °C |
| Time Range | 1 s to 99 min 59 s |
| Noise | ≤ 65 dB |
| Refrigeration System | CFC-free compressor, R404a |
| Power Supply | AC 220 V 50/60 Hz |
| Dimensions (L × W × H) | 785 × 670 × 445 mm |
| Packaging Dimensions (L × W × H) | 807 × 904 × 719 mm |
| Net Weight | 105 kg |
| Gross Weight | 130 kg |
Features
- CFC-free refrigerant
- Explosion-proof design
- Microprocessor controller
- Electromechanical door lock
- Over temperature protection
Applications
- High Speed Refrigerated Microcentrifuge is essential for cell pelletation, subcellular fractionation, blood sample processing, drug formulation and quality analysis.
Optional Rotor Selection
Rotor Type No. Maximum Speed Maximum Capacity Maximum RCF Angle Rotor 1 21000 r/min 12 × 1.5 mL 31061 × g Angle Rotor 2 21000 r/min 12 × 2 mL 31061 × g Angle Rotor 3 18000 r/min 18 × 1.5 mL 27167 × g Angle Rotor 4 18000 r/min 18 × 2 mL 27167 × g Angle Rotor 5 16000 r/min 24 × 1.5 mL 25759 × g Angle Rotor 6 16000 r/min 24 × 2 mL 25759 × g Angle Rotor 7 13500 r/min 36 × 1.5 mL 19159 × g Angle Rotor 8 13500 r/min 36 × 2 mL 19159 × g Angle Rotor 9 13000 r/min 48 × 1.5 mL 19159 × g Angle Rotor 10 13000 r/min 48 × 2 mL 19159 × g Angle Rotor 11 18000 r/min 24 × 0.5 mL 20035 × g Angle Rotor 12 18000 r/min 30 × 0.5 mL 15210 × g Angle Rotor 13 16000 r/min 12 × 10 mL 25473 × g Angle Rotor 14 16000 r/min 8 × 7 mL 21466 × g Angle Rotor 15 16000 r/min 10 × 5 mL 20035 × g Angle Rotor 16 15000 r/min 40 × 0.2 mL 21695 × g Angle Rotor 17 15000 r/min 40 × 0.5 mL 15267 × g Angle Rotor 18 6000 r/min 12 × 10 mL 4387 × g Angle Rotor 19 6000 r/min 12 × 15 mL 4387 × g
Adapter Selection
Adapter No. Maximum Speed Maximum Capacity Maximum RCF Adapter 1 21000 r/min 12 × 0.2 mL 31061 × g Adapter 2 21000 r/min 12 × 0.5 mL 31061 × g Adapter 3 18000 r/min 18 × 0.2 mL 27167 × g Adapter 4 18000 r/min Alternative Models Of High Speed Refrigerated Microcentrifuge
Fison High Speed Refrigerated Microcentrifuge are specifically designed for separation of temperature sensitive samples. Their high-performance compressor maintains a broad temperature range of -20 ? to 40 ?. They feature CFC-free refrigerant, LCD display and programmable settings for process monitoring. They come with a variety of rotor options including fixed-angle, swing-bucket, or microtube type. Our High Speed Refrigerated Microcentrifuge can hold wide range of sample volumes from 0.2 mL to 10 mL.
High Speed Refrigerated Microcentrifuge FM-HMC-A100
- Capacity: 12 × 5 ml
- Maximum Speed: 14000 rpm
- Maximum RCF: 18800 × g
Low Speed Centrifuge
Fison Low Speed Centrifuges are designed for efficient separation of biological and chemical samples. They offer reliable low speed centrifugation, ensuring gentle handling of sensitive materials. These units feature a user-friendly control panel, allowing easy speed and time adjustments. They include a lid-lock mechanism and imbalance detection for enhanced safety. Our centrifuges are equipped with multiple rotors to accommodate various sample types and volumes for versatile use.
Low speed centrifuge FM-LSC-A100
- Maximum speed : 4000 rpm
- Maximum RCF : 2432 × g
- Rotor capacity : 15 ml/ 20 ml × 6
Low speed centrifuge FM-LSC-A101
- Maximum speed : 6000 rpm
- Maximum RCF : 5000 × g
- Rotor capacity : 100 ml × 4
Low Speed Centrifuge FM-LSC-A102
- Maximum speed : 6000 rpm
- Maximum RCF : 5000 × g
- Rotor capacity : 450 ml × 4
Low Speed Refrigerated Centrifuge
Fison Low Speed Refrigerated Centrifuges are designed for efficient separation of temperature-sensitive biological and chemical materials. They offer stable and adjustable temperature control, ensuring optimal conditions for sample preservation. These units feature a user-friendly control panel for easy operation and monitoring. They are equipped with multiple rotor options, accommodating various sample volumes for versatile applications. Our centrifuges deliver quiet and stable operation, minimizing noise and vibration to enhance laboratory efficiency.
Low Speed Refrigerated Centrifuge FM-LRC-A100
- Maximum speed : 4200 rpm
- Maximum RCF : 3387 ×g
- Swing rotor capacity : 4 × 600 ml
Low Speed Refrigerated Centrifuge FM-LRC-A101
- Maximum speed : 4200 rpm
- Maximum RCF : 5116 ×g
- Swing rotor capacity : 6 × 1000 ml
Low Speed Refrigerated Centrifuge FM-LRC-A102
- Maximum speed : 8000 rpm
- Maximum RCF : 11068 ×g
- Swing rotor capacity : 6 × 2400 ml
High Speed Centrifuge
Fison High Speed Centrifuge applies large centrifugal force to separate sample components. They come with microprocessor regulated LCD Display for easy monitoring. Cooling systems protect heat-sensitive samples by maintaining sub-zero temperatures. They feature multiple working modes along with noise-free operation. We offer High Speed Centrifuge with different speed settings, ranging from 6000 to 23000 rpm.
Benchtop High-Speed Centrifuge FM-BHC-A100
- Maximum RPM : 24000 r/min
- Maximum RCF : 47800 × g
- Maximum Capacity : 4 × 100 ml
High Speed Centrifuge FM-HSC-A100
- Maximum speed : 6000 rpm
- Maximum RCF : 1248 × g
- Maximum capacity : 2 × 8 × 0.2 ml
High Speed Centrifuge FM-HSC-A101
- Maximum speed : 10000 rpm
- Maximum RCF : 6596 × g
- Maximum capacity : 12 × 1.5 / 0.5 / 0.2 ml
High Speed Refrigerated Centrifuge
Fison High Speed Refrigerated Centrifuges are designed for rapid and precise separation while maintaining accurate temperature control. They provide an advanced cooling system, maintaining stable temperatures to protect heat-sensitive samples. These units are equipped with multiple rotor types for versatile applications. Our centrifuges deliver low noise and vibration, ensuring a quiet and stable laboratory environment. They feature durable and corrosion-resistant construction for long-term use.
High speed Refrigerated Centrifuge FM-HRC-A303
- Maximum speed : 21000 r/min
- Maximum RCF : 31300 × g
- Maximum Capacity : Angle rotor : 600 ml
Swing rotor : 3000 ml
High Speed Refrigerated Centrifuge FM-HRC-A100
- Maximum speed : 18000 rpm
- Maximum RCF : 23846 × g
- Maximum capacity : 24 × 0.5 ml
High Speed Refrigerated Centrifuge FM-HRC-A101
- Maximum speed : 23000 rpm
- Maximum RCF : 33097 × g
- Maximum capacity : 6 × 250 ml
Mini Centrifuge
Fison Mini Centrifuge features a transparent lid design, allowing easy observation of samples during operation. They provide protection at high speed, preventing damage from excessive forces or rapid movements. Their adoption of high-frequency broad voltage technology ensures stable performance across varying voltage levels. The rotor snaps allow for easy replacement, reducing downtime and ensuring continuous, efficient operation. Our mini centrifuge uses the opening and closing of the lid as the stop or start mechanism, ensuring safe and efficient operation.
Mini Centrifuge FM-MC-A100
- Maximum speed : 4000 rpm
- Maximum RCF : 900 × g
- Speed accuracy : ±20 rpm
Mini Centrifuge FM-MC-A101
- Maximum speed : 6000 rpm
- Maximum RCF : 2000 × g
- Speed accuracy : ±20 rpm
Mini Centrifuge FM-MC-A102
- Maximum speed : 10000 rpm
- Maximum RCF : 5500 × g
- Speed accuracy : ±20 rpm
