- ✔ Small size, lightweight, and easily handled
- ✔ Flexible mounting options for both horizontal and vertical pipes
- ✔ Reliable measuring device unaffected by working time
- ✔ Resistant to magnetic field interference up to 100 ka/m
- ✔ Measurement and remote transmission capabilities are unaffected
- ✔ Includes non-volatile memory to store flow rate and time data during a power outage
- ✔ Can store up to 18 months' record
- ✔ Dual-purpose heat and cold energy meter that can be installed in either the return or forward flow line
- ✔ Provided clever design that can track energy and flow volume
| Diameter |
DN32 |
| Min. Flow qmin |
0.12 m³/h |
| Quantity of Flow (qp) |
6 m³/h |
| Max Flow qmax |
12 m³/h |
| Length |
180mm |
| Connection |
Threaded connection |
| Pressure Loss |
≤0.02MPa |
| Maximum Working Pressure (MWP) |
1.6MPa |
| Flow Measuring Range |
0.1 |
| Temperature Sensor |
1.5m standard a pair of PT1000 Temperature Sensors （cable length could be changed） |
| Remote Transmission |
M-bus, RS485, LORA, LORAWAN, NB-IOT |
| Power Supply |
High Power Lithium battery |
| Environmental Class |
Class B |
| Temperature Range |
5 to 95℃ |
| Temperature Difference |
3 to 90 K |
| Installation Way |
Inflow or Return flow（Default is Inflow, for return flow need to indicate when ordering） |
| Installation Position |
Horizontal / Vertical |
| Permanence |
Service cycle≥6 years |
| Display |
8-bit LCD |
| Dimensions |
22 ×11.5 ×13 cm |
| Weight |
1.2 kg |
Heat flow calorimeters are versatile tools for measuring heat transfer in reactors, allowing users to monitor heat flow while maintaining process temperature control and widely used in urban heating pipes, heating tables of residential buildings, and heating systems.
