- ✔ Halogen lamp heating mode
- ✔ Ergonomically designed pan handle
- ✔ 7-inch smart touch LCD display
- ✔ Automatic sensor opening door of heating chamber
- ✔ Displays test values as percentage of dry weight (%) / Moisture (% m) / the weight (g)
- ✔ Weighing range: 4 mg to 110 g
- ✔ Weighing resolution or readability: 0.001 g
- ✔ Moisture content measuring range: 0.00 to 100.00 %
- ✔ Moisture content resolution or readability: 0.01 %
- ✔ Adjustable drying time and temperature
- ✔ Memory stores up to 20 drying profiles
- ✔ Long distance operation using smart touch panel
- ✔ Maximum 230°C heating temperature
- ✔ Testing Mode:
- ✔ Auto Mode: The mode is suitable for most of the samples for common moisture analysis
- ✔ Soft Mode: Some fusible and volatility things can choose this mode
- ✔ Fast Mode: Some stable and thermostable things can choose this mode
- ✔ Stainless steel drying pan is quick and easy to clean
- ✔ Manual setting for temperature and time
- ✔ Wireless communication mode using 10,000 mAh battery and RS232/RJ45/USB interface
| Range |
4 mg to 110 g |
| Readability |
1 mg |
| Temperature range |
40 to 230 °C |
| Communication mode |
Wireless |
| Rechargeable battery |
10,000 mAh battery |
| Heat source |
Halogen lamp |
| Pan size |
100 mm diameter |
| Operating temperature range |
5 to 35°C |
| Temperature sensor |
PT-100 |
| Temperature step |
1°C |
| Temperature setting |
40 to 230°C by 1°C |
| Time setting |
1 to 99 min by 10s |
| Dry residual range |
0 to 100 % |
| Dry residual readability |
0.0001 |
| Moisture range |
0 to 100 % |
| Moisture readability |
0.0001 |
| Number of storage data |
20 |
| Number of history data |
20 |
| Heater part power |
220 V ± 15 % 50 Hz, 110 V ± 15 % 60 Hz, 400 W |
| Balance part power |
Input: 220 V 50 Hz/ 110 V 60 Hz, Output: 9 V |
| Mechanical part machine |
Input: 220 V 50 Hz/ 110 V 60 Hz, Output: 24 V (dual –drive) |
| Display |
7 inch touch panel |
| Interface |
RS232/USB |
| Operation height |
275 mm |
| Chamber height |
35 mm |
| Indicator dimension |
200 × 75 × 135 mm |
| Unit dimension |
215 × 195 × 415 mm |
| Gross weight |
10 kg |
Suitable for the testing and analysis of samples of materials such as wood, pellets, biomass, granules, feed, food products and pastes. Also, designed for food, plastics and chemical moisture analysis.
| Accessories no |
Accessories name |
Units |
| 1. |
Moisture Analyzer Mainframe |
1 set |
| 2. |
Wind Cover |
1 piece |
| 3. |
The sample pan holder |
1 piece |
| 4. |
Tray handle |
1 piece |
| 5. |
Aluminum sample pan |
1 set of 50pcs |
| 6. |
100g standard weight |
1 piece |
