| Throughput | 80 Tests / hour |
| Measurement Method | Infrared detection |
| Analysis Result | Westergren ESR value (mm/hour) |
| Measurement Range | 0 to 120 mm/h |
| Blood Level Range | 50 mm to 64 mm |
| Haematocrit (HCT) Range | 0.2 to 1 |
| Reading Accuracy | 0.2 mm |
| Channel Error | ≤ ±4 mm/h |
| Number Of Analysis Channels | 40 |
| Channel Consistency | 0 to 10 mm/h, SD ≤ 1.5 mm/h, > 10 mm/h, CV ≤ 15% |
| Repeatability | 0 to 10 mm/h, SD ≤ 1.5 mm/h, > 10 mm/h, CV ≤ 15% |
| Analysis Time | 30 or 60 min |
| Sampling Interval | 3 min |
| Result Accuracy |
±2mm/h (ESR ≤ 30mm/h) ±3mm/h (30mm/h < ESR ≤ 80mm/h) ±5mm/h (ESR > 80mm/h) |
| Result Precision | CV ≤ 2% |
| Result Resolution | 1 mm/h |
| Temperature Compensation | Automatically corrected to result at 18°C |
| Display | 7-inch colour LCD touch screen |
| Communication Interface | RS232 serial interface |
| Printer | Built-in thermal printer |
| Power Supply | AC 220 V, 50 to 60 Hz |
| Dimensions (W × D × H) | 360 × 300 × 180 mm |
| Packaging Dimensions (W × D × H) | 395 × 335 × 375 mm |
| Net Weight | 7.3 kg |
| Gross Weight | 10 kg |
