- ✔ Floor standing type
- ✔ Microprocessor PID control system
- ✔ Vertical force convection and bottom heating
- ✔ Exhaust fan for temperature uniformity in chamber
- ✔ Corrosion resistance stainless steel chamber
- ✔ Platinum gold resistor PT100 temperature sensor
- ✔ Steel outer shell with static plastic spraying
- ✔ Three layer toughened glass observation window
- ✔ Adjustable stainless steel shelves
- ✔ Self-diagnostic dynamic control technology
- ✔ Temperature controller with sensor malfunction and low/ high temperature deviation alarm
| Chamber volume |
230 L |
| Method |
The aplomb forces convection |
| Temperature range |
Ambient temperature + 10 to 200°C |
| Temperature accuracy |
±1 at 100°C |
| Temperature fluctuation |
± 1°C |
| Temperature uniformity |
± 2.5°C |
| Temperature controller |
(The PID microprocessor controls, touch type, numeral manifestation) |
| Temperature sensor |
PT100 (Platinum gold resistor PT100) |
| Timer |
Wait on time, wait off time (Maximum: 99 h, Minimum: 1 min) |
| Environmental condition |
Temperature 5 to 30°C |
| Maximum relative humidity |
Maximum relative humidity 80% |
| Altitude |
up to 2000 m |
| Internal material |
304 stainless steels |
| External material |
08F (Iron 08F) |
| Number of shelves (Standard/Maximum) |
2/4 |
| Shelf dimension |
493 mm × 580 mm |
| Power |
2000 W |
| Power supply |
AC 220 V, 50 Hz |
| Internal dimension |
500 × 600 × 750 mm |
| External dimension |
880 × 720 × 930 mm |
| Weight |
90 kg |
Used for glassware desiccation, laboratorial sample, food, chemical materials heat denaturalization, heat induration, moisture elimination, biomedical and other instruments sterilization; electronic components torrefaction and aging.
| Accessories no. |
Accessories name |
Unit |
| 1 |
Motor |
1 |
| 2 |
Sealing ring |
1 |
| 3 |
Temperature controller |
1 |
| 4 |
Plastic handle |
1 |
| 5 |
Stainless steel handle |
1 |
