| External Dimension (W×D×H) | 1873×775×2295 mm |
| Internal Dimension (W×D×H) | 1700×600×660 mm |
| Work Surface Height | 750 mm |
| Max Opening | 550 mm (22 inch) |
| Tested Opening | Safety height 254 mm (10 inch) |
| Air flow Volume |
In flow: 824 m3/h (485 cfm) Down flow: 60%: 1212 m3/h (713 cfm) Exhaust: 40%: 824 m3/h (485 cfm) |
| Front Window Thickness | ≥ 5 mm |
| HEPA Filter | Two, 99.999% efficiency at 0.3 um |
| Filter Guard Type | Aluminium alloy frame |
| Noise | NSF 49 ≤ 61 dB/EN 12469 ≤ 58 dB |
| Illumination | ≥ 1000 Lux |
| Display | LCD Display |
| Waterproof Socket |
Two Total consumption: ≤ 500 W |
| Tap | Water tap × 1, Gas tap × 5 |
| Ground Resistance | ≤ 0.10 Ω |
| Power Supply | AC 220 V ± 10%, 50/60 Hz; 110 V ± 10%, 60 Hz, Full load Amps: 9A, BTU/Hr: 1693 |
| Consumption | 500 W |
| DC Motor | One ECM motor, 110V & 220V acceptable, Speed adjustable |
| Material |
Working area: 304 stainless steel Frame and Decorative Plate: cold-rolled steel with anti-bacteria power coating. |
| UV Lamp |
40 W Emission of 253.7 nanometers |
| Illumination Lamp | 22 W ×2 |
| Packaging Dimension (W×D×H) | 2020×1080×1900 mm |
| Weight | 370 kg |
