Automatic Liquid Extraction Rotary Agitator FM-ARA-B100 Catalog

Description :

Automatic Liquid Extraction Rotary Agitator FM-ARA-B100 is a microprocessor controlled, sample agitating device with 8 pcs separating funnel and 15 to 40 rpm adjustable speed. Designed with active sliding door for easy loading and unloading of separation funnel. Device features electricity insulated flip cover, electricity leakage protection and overload protection for safety of the user. Used during liquid-liquid extraction procedure in environment protection industry and disease control and research labs.

Features:

---

Specifications:

---

Vessel (Funnel) loaded	8 pcs
Separating funnel capacity	500, 1000 and 2000 ml
Separating funnel type	Glass
Rotation method	(Positive 360° over turn rotations for 2 min and stop for 5 seconds) (Reverse for 3 min and stop for 5 seconds)
Rotation speed	Adjustable, 15 to 45 rpm
Rotation accuracy	± 1 rpm
Display	LCD display
Time setting	Minute/hour setting, 1-24 hour for alternative, accuracy to minute
Continous working time	18 hours
Temperature	RT to 65°C
Temperature accuracy	± 0.5 °C
Power supply	AC 220 V, 50 Hz
Pacakging dimension	1120 × 420 × 620 mm
Net weight	47 kg
Gross weight	59 kg

Applications: Used during liquid-liquid extraction procedure in environment protection industry and disease control and research labs.
