Air Cooled Chiller FM-AC-A102
Air Cooled Chiller FM-AC-A102 is equipped with a cooling capacity of 12.5KW to deliver consistent thermal management. It features a hermetic scroll compressor offering smooth operation. Silent performance high-efficiency copper-aluminium fin condenser enhances energy output. It is designed to meet demanding industrial needs with reliable and long-lasting performance.
Specifications
| Cooling capacity | 12.5 KW, 10750 Kcal/h |
| Compressor type | Hermetic scroll |
| Operation power | 4.64 kw |
| Ambient temperature | Greater than 45°C |
| Refrigerant species | R404a |
| Control mode | Expansion valve |
| Flow of refrigerated water | 2.15 m3/h |
| Pipe size | DN25 |
| Condenser | High performance copper cover aluminium fin |
| Evaporator type | Expansion valve |
| Noise lever | 60Db |
| protector | Anto-phase protection, no water protection, overload protection, compressor over temperature protection, high and low pressure protection |
| Power supply | 380V/50Hz |
| Dimension (L×B×H) | 1300×710×1300 mm |
| Weight | 165 kg |
Features
- Fast thermal regulation
- Integrated safety circuits
- Easy component access
- Heavy duty build
Applications
- Fison’s Air Cooled Chiller FM-AC-A102 is ideal for precise cooling in laboratories, process industries and controlled environments demanding consistent thermal management and reliable refrigeration cycles.
